CH.4.13 - USB 4.0 Type C Gen.3x2

► Most compact size USB Type-C Receptacle (L 6.58mm* W 12.04mm* H 3.22mm)
► Improve and reduce EMI / RFI from high frequency signals
► Compatible with USB Type-C Specification
► Compatible with USB Power Delivery & Supports up to 8A max. power supply
► Reversible plug makes it possible to insert both ways
► Lock structure with superior durability
► Large selection of connector variations are available
► SMT Contact Horizontal Receptacle
   • Single-row SMT type receptacle connector design with a mounting area space-saving is also the best solution for SMT processes. Compliant with Universal Serial Bus Type-C Specification Release 3.2 & Super Speed communication. (USB 3.2 Gen.2)
Product  CH. Type SPEC. SPEED
 USB C (Receptacle)   0.10 mm  Sink  USB 4 Gen 3X2  40G
 1.58mm  Top  USB 4 Gen 3X2  40G
 3.40mm  Top  USB 4 Gen 3X2  40G
 4.13mm  Top  USB 4 Gen 3X2  40G
