Reverse (反向) CH.1.58 - USB 3.1 Type A Gen.1

► Most compact size USB Type-A Receptacle (L 11.2mm* W 13.8mm* H 5.72mm)

► Improve and reduce EMI / RFI from high frequency signals

► Compatible with USB Type-A Specification

► Compatible with USB Power Delivery & Supports high power supply

► Single-row SMT type receptacle connector design with a mounting area space-saving is also the best solution for SMT processes. Compliant with Universal Serial Bus Type-A Specification Release 3.2

► Lock structure with superior durability

► Large selection of connector variations are available

Product  CH. Type SPEC. SPEED
 USB A (Receptacle)   0.10mm  Sink  USB 3.2 Gen 1  5G
 0.8mm  Sink  USB 3.2 Gen 1  5G
 1.58mm  Sink  USB 3.2 Gen 1  5G
 2.95mm  Top  USB 3.2 Gen 1  5G
 3.40mm  Top  USB 3.2 Gen 1  5G
 4.13mm  Top  USB 3.2 Gen 1  5G
 11.20mm  Vertical  USB 3.2 Gen 1  5G
