► TID (Test ID) & IEC-62680-1 approved
► Most compact size USB Type-A Receptacle (L 11.2mm* W 13.8mm* H 5.72mm)
► Improve and reduce EMI / RFI from high frequency signals
► Compatible with USB Type-A Specification
► Compatible with USB Power Delivery & Supports high power supply
► Single-row SMT type receptacle connector design with a mounting area space-saving is also the best solution for SMT processes. Compliant with Universal Serial Bus Type-A Specification Release 3.2 & Super Speed communication. (USB 3.2 Gen.2)
► Lock structure with superior durability
► Large selection of connector variations are available
180° CH.15.5 - USB 3.2 Type A Gen.2
| Product | CH. | Type | SPEC. | SPEED |
| USB A (Receptacle) | 0.10mm | Sink | USB 3.2 Gen 2 | 10G |
| 0.8mm | Sink | USB 3.2 Gen 2 | 10G | |
| 1.58mm | Sink | USB 3.2 Gen 2 | 10G | |
| 2.95mm | Top | USB 3.2 Gen 2 | 10G | |
| 3.40mm | Top | USB 3.2 Gen 2 | 10G | |
| 4.13mm | Top | USB 3.2 Gen 2 | 10G | |
| 11.20mm | Vertical | USB 3.2 Gen 2 | 10G |
